White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System
  • White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System
  • White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System
  • White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System
  • White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System
  • White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System

White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System

Place of Origin China
Brand Name JT-RESIN
Certification SGS,CE,UL
Model Number 8068
Product Details
Color:
White
Industry:
Electrical Insulator
Thermal Class:
F
Application Environment:
High Temperature
Name:
Epoxy Electrical Insulation System
Process:
Conventional Vacuum Self Gravity Casting
Main Raw Material:
Epoxy
Einecs No.:
210-898-8
Classification:
Double Components Adhesives, Other Adhesives
High Light:

White High Temp Epoxy Resin

,

High Temp Epoxy Resin Hardener

,

White Fast Drying Epoxy

Payment & Shipping Terms
Minimum Order Quantity
25KG
Price
$3/kg
Packaging Details
1200kgs/pail
Delivery Time
5 days
Payment Terms
L/C, T/T, Western Union, MoneyGram
Supply Ability
200Ton/week
Product Description

Factory price Epoxy Resin and High temperature Hardener for Class F Dry Type Transfomer

Applications:

For medium and high voltage indoor transformer,electrical insulators, such as switches and electrical parts, etc



Processing methods:

Conventional vacuum self gravity casting



Product data(Guideline values) *



JT 8068-1 A Liquid and Solvent free modified epoxy resin

TYPICAL VALUES*

Viscosity @ 25, mPa.s [ISO 12058] .................................................................. 1,500-3,000

Epoxy value, equiv/g [ISO 3001] .............................................................................0.45-0.51

Density @ 25℃ , g/cm3 [ISO 1675] ........................................................................1.13--1.15

Vapor pressure @20°C, pa (knudsen) ...........................................................................<0.01

@60°C, pa(knudsen) ..............................................................................<0.5

Storage life @ 25℃ (sealed container), month ……………………………………………………………..12

Remark:In order to prevent the absorption of moisture,please keep epoxy resin in sealed container and storage under normal temperature (about 20 to 25℃).

White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System 0White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System 1White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System 2White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System 3



JT 8068-1 B Modified liquid Epoxy hardener

TYPICAL VALUES*

Viscosity @ 25℃, mPa.s [ISO 12058] ............................................................................50-80

Vapour Pressure @ 20℃, mbar( Knudsen)....................................................................Ca.0.5

@ 60℃,mbar(Knudsen) .....................................................................Ca.10

Density @ 25℃ , g/cm3 [ISO 1675] .........................................................................1.19-1.22

Storage life @ 25℃ (sealed container), month …………………………………………………………….12











Application area:

White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System 4White High Temp Epoxy Resin Hardener Fast Drying Electrical Insulation System 5
