Electrical Transformer Epoxy Resin Non Flammable High Hermal Stability


JT 8524A Epoxy Resin 100 pbw
JT 8524B Epoxy Hardener 80 pbw
Silica filler 270 pbw



Liquid, Hot-curing cast resin system for outdoor electrical insulation material for medium and high voltage applicaions.


JT 8524A/JT8524 B is epoxy resin system formulated for indoor electrical insulator parts. This product doesn't contain solvent, and has excellent mechanical and electrical performance


Summary


Excellent mechnical and electrical performance Properties
High thermal shock resistance
Excellent long term breakdown resistance


For medium and high voltage indoor electrical insulator parts, and fiber reinforced Application

And filler reinforced cast resin transformer,instrument transformer, etc.

Hubei Jiangte Insulation Composite Guangzhou Jiangte Insulation Composite Add:No.219,Zhanghua Rd(N),Economic & Development Add:Rm606,DongHong International Plaza, No.

Zone of Qianjiang City, Hubei Province, China. 113, Chebei Rd, Tianhe District, Guangzhou,China.

Tel:+86-728-6201068 Tel:+86-20-82320316

Fax:+86-728-6202066 Fax:+86-20-82315407


Processing Methods
Conventional vacuum cast technology, mould temperature range is 70℃–80℃, demoulding time is about 5-8h(different as per temperature and volume). After cure at 130℃ and keep warm for 10h.

The demould time and after cure cycle need to be determined as per specific product design and process technology. Pls contact our technicians for more info.

Product data (guideline values)

JT 8524A Liquid modified Epoxy resin

Remark: To avoid water absorption, putting epoxy resin inside sealed container and keep at temperature 20-25℃ are suggested

JT 8524 B Pre catalytic liquid anhydride curing agent

* typical value can not be regarded as product specs

Remark: This hardener is sensitive to water. If water content is high, which may change its reactivity, and finally change its performance. It must be stored in sealed container and kept in normal temperature( about 20–25℃).


Process data (guideline values)

General instructions for preparing liquid resin systems
Long pot life is desirable in the processing of any ARALDITE casting resin system. Mix all of the components together very thoroughly at room temperature or slightly above and under vacuum. Intensive wetting of the filler is extremely important. Proper mixing will result in:
• better flow properties and reduced tendency to shrinkage
• lower internal stresses and therefore improved mechanical properties on object
• improved partial discharge behavior in high voltage applications.
For the mixing of medium- to high viscous Epoxy casting resin systems and for mixing at lower temperatures, we recommend special thin film degassing mixers that may produce additional self-heating of 10-15 K as a result of friction. For low viscous Epoxy casting resin systems, conventional anchor mixers are usually sufficient. The prefilled Epoxy resin and Hardener can be stored at elevated temperature (about 60°C) for up to about 1 week, de-pending on formulation. Intermittent agitation during storage is advisable to prevent filler sedimentation.

Mixing time can vary from 0.5 to 3 hours, depending on mixing temperature, quantity, mixing equipment and the particular application. The required vacuum is 0.5 to 8 mbar. The vapour pressure of the individual components should be taken into account.

System Preparation
