White Epoxy Resin Curing Agent Electrical Insulating With Silica Flame Resistant
  • White Epoxy Resin Curing Agent  Electrical Insulating With Silica Flame Resistant
  • White Epoxy Resin Curing Agent  Electrical Insulating With Silica Flame Resistant
  • White Epoxy Resin Curing Agent  Electrical Insulating With Silica Flame Resistant

White Epoxy Resin Curing Agent Electrical Insulating With Silica Flame Resistant

Place of Origin China
Brand Name JT-RESIN
Certification SGS,CE,UL
Model Number JT8837AB
Product Details
Shape:
Iiquid
Color:
White
Industry:
Electrical Insulator
Application Environment:
High Temperature
Name:
Epoxy Electrical Insulation System
Process:
Conventional Vacuum Self Gravity Casting
Compound:
3
Appearance:
Colorless To Light Yellow Liquid
Curing Agent Compatibility:
Compatible With Epoxy Resin
Curing Agent Content:
10-30%
Curing Agent Dosage:
2-3%
Curing Agent Ratio:
1:1
Curing Pressure:
0-2MPa
Curing Temperature:
80-120℃
Curing Time:
2-3 Hours
Flash Point:
>100℃
Product Name:
Epoxy Resin Curing Agent
Shelf Life:
12 Months
Solubility:
Soluble In Alcohol, Ether, Benzene And Other Organic Solvents
Specific Gravity:
1.05-1.15
Storage Temperature:
0-40℃
Viscosity:
25-50 Cps/25℃
High Light:

White Epoxy Curing Agent

,

Flame Resistant Epoxy Curing Agent

,

Electrical Insulating Flame Resistant Epoxy

Payment & Shipping Terms
Minimum Order Quantity
25KG
Price
$3/kg
Packaging Details
1200kgs/pail
Delivery Time
5 days
Payment Terms
L/C, T/T, Western Union, MoneyGram
Supply Ability
200Ton/week
Product Description

White Epoxy Resin Curing Agent with Silica for Indoor and Outdoor 10 to 1100KV Insulators

TDS:





JT 8837A Epoxy Resin 100 pbw

JT 8837B Epoxy Hardener 80 pbw

Silica filler(Silanised treated) 300 pbw





Liquid, Hot-curing cast resin system for outdoor electrical insulation material for medium and high voltage application



Epoxy coating powder JT105 can be a useful material for electrical insulation of wire and busbars, as well as high performance motors. Here are some features and benefits of JT105 epoxy coating powder:

Electrical Insulation: Epoxy coating powder JT105 is an excellent electrical insulator, which makes it ideal for use in electrical insulation applications. It can help to prevent electrical current from flowing through the insulation, reducing the risk of electrical breakdown or short circuits.

Corrosion Protection: Epoxy coating powder JT105 is highly resistant to corrosion, which makes it a good choice for use in harsh environments, where exposure to moisture or other corrosive substances could cause damage or corrosion.

Chemical Resistance: Epoxy coating powder JT105 is highly resistant to chemicals, which makes it a good choice for use in applications where exposure to chemicals could cause damage or corrosion.

Mechanical Protection: Epoxy coating powder JT105 can also provide mechanical protection to the wire, busbars, or motor components. The coating can help to strengthen the components, making them more resistant to bending, cracking, or breaking.

Customizable: Epoxy coating powder JT105 can be formulated to meet specific performance requirements, such as low viscosity, high filler loading, or high thermal stability. This makes it a versatile material that can be customized to meet the needs of different applications.

Overall, epoxy coating powder JT105 can be an effective and reliable material for electrical insulation of wire and busbars, as well as high performance motors. Its combination of electrical insulation, corrosion protection, chemical resistance, mechanical protection, and customization options make it a popular choice for manufacturers of electrical equipment.

Current and potential transformers



Applications





Conventional casting with stage wise curing, or pressure gelation or Processing methods

Automatic pressure gelation casting (PG or APG process).







Very good mechanical and electrical properties. Properties

Good temperature shock resistance.

Use of silanized fillers enhances stability of dielectric properties under high-humidity condition.

Very good resistance to erosion by UV radiation.













Application area:
