Liquid Electrical Insulating Epoxy Resin Light Yellow Casting Quick Dry Cure
  • Liquid Electrical Insulating Epoxy Resin Light Yellow Casting Quick Dry Cure
  • Liquid Electrical Insulating Epoxy Resin Light Yellow Casting Quick Dry Cure
  • Liquid Electrical Insulating Epoxy Resin Light Yellow Casting Quick Dry Cure

Liquid Electrical Insulating Epoxy Resin Light Yellow Casting Quick Dry Cure

Place of Origin China
Brand Name JT-RESIN
Certification ISO.CE.UL
Model Number JT 8824A&B
Product Details
Viscosity::
0.4-0.8
Usage::
Medium@high Voltage Insulation Switch Parts
Main Raw Material::
Epoxy
Flash Point::
140
Color::
Light Yellow
High Light:

Cure Electrical Insulating Epoxy

,

Light Yellow Electrical Insulating Epoxy

,

Light Yellow Quick Dry Epoxy

Payment & Shipping Terms
Minimum Order Quantity
25KG
Price
$2/kg
Packaging Details
1200kgs/pail
Delivery Time
3 days
Payment Terms
L/C, T/T, Western Union, MoneyGram
Product Description

Liquid electrical insulation epoxy resin casting resin for medium&high voltage LBS, BUSHINGS, SPOUTS

Electrical Insulation Materials

Epoxy coating powder JT105 can be a useful material for electrical insulation of wire and busbars, as well as high performance motors. Here are some features and benefits of JT105 epoxy coating powder:

1.Electrical Insulation: Epoxy coating powder JT105 is an excellent electrical insulator, which makes it ideal for use in electrical insulation applications. It can help to prevent electrical current from flowing through the insulation, reducing the risk of electrical breakdown or short circuits.

2.Corrosion Protection: Epoxy coating powder JT105 is highly resistant to corrosion, which makes it a good choice for use in harsh environments, where exposure to moisture or other corrosive substances could cause damage or corrosion.

3.Chemical Resistance: Epoxy coating powder JT105 is highly resistant to chemicals, which makes it a good choice for use in applications where exposure to chemicals could cause damage or corrosion.

4.Mechanical Protection: Epoxy coating powder JT105 can also provide mechanical protection to the wire, busbars, or motor components. The coating can help to strengthen the components, making them more resistant to bending, cracking, or breaking.

5.Customizable: Epoxy coating powder JT105 can be formulated to meet specific performance requirements, such as low viscosity, high filler loading, or high thermal stability. This makes it a versatile material that can be customized to meet the needs of different applications.





Processing Methods



Conventional vacuum cast technology, mould temperature scope is 130℃–150, demoulding time is about 10-30min(different as per temperature and volume). After cure at 140℃ and keep warm for 8h.



The demoulding time and after cure cycle need to be determined as per specific product design and process technology. Please contact our technicians for more info.



Product data (guideline values)





JT 8824A Liquid modified Epoxy resin

TYPICAL VALUES*

Viscosity@25℃, mPa.s[ASTM D-2983] ................................................................5000–12000



Non volatile component, wt% [DOWM-101188-TE]...........................................................100



Density@25℃, g/ cm3 [ASTM D-1475] ....................................................................1.10–1.20



Storage life@25℃(sealed container), month.......................................................................12



Remark: To avoid water absorption, putting epoxy resin inside sealed container and keep at temperature 20-25℃ are suggested



JT 8824 B Pre catalytic liquid anhydride curing agent

TYPICAL VALUES*

Viscosity @ 25℃, mPa.s [ASTM D-2983] .....................................................................300-400



Density @ 25℃, g/cm3 [ASTM D-1475] ..................................................................1.15–1.25



Vapor pressure @ 25℃, mbar ......………………………………………………………………………………...1 - 2



Storage life @ 25℃(sealed container), month......................................................................12

* typical value can not be regarded as product specs



Remark: This hardener is sensitive to water. If water content is high, which may change its reactivity, and finally change its performance. It must be stored in sealed container and kept in normal temperature( about 20–25℃).
