Casting Epoxy Resin Curing Agent Transformer UV Resistant Non Toxic Liquid
  • Casting Epoxy Resin Curing Agent Transformer UV Resistant Non Toxic Liquid
  • Casting Epoxy Resin Curing Agent Transformer UV Resistant Non Toxic Liquid
  • Casting Epoxy Resin Curing Agent Transformer UV Resistant Non Toxic Liquid
  • Casting Epoxy Resin Curing Agent Transformer UV Resistant Non Toxic Liquid

Casting Epoxy Resin Curing Agent Transformer UV Resistant Non Toxic Liquid

Place of Origin China
Brand Name JT-RESIN
Certification SGS,CE,UL
Model Number JT8897AB
Product Details
PROCESS:
APG
Main Raw Material:
EPOXY
KEY WORDS:
EPOXY RESIN
Application:
ELECTRICAL INSULATION
SHAPE:
LIQUID
High Light:

UV Resistant Epoxy Curing Agent

,

Non Toxic Epoxy Curing Agent

,

Non Toxic Casting Resin Agent

Payment & Shipping Terms
Minimum Order Quantity
25KG
Price
$3/kg
Packaging Details
1200kgs/pail
Delivery Time
5 days
Payment Terms
L/C, T/T, Western Union, MoneyGram
Supply Ability
200Ton/week
Product Description

casting Epoxy resin curing agent for M&H voltage current Transformer and Electrical insulation

TDS:



Electrical Insulation Materials





JT 8897A Epoxy Resin 100 pbw

JT 8897B Epoxy Hardener 90 pbw

Silica filler 330-350 pbw

JT 8897A JT 8897B




Product data (guideline values)



JT 8897A Liquid modified Epoxy resin

TYPICAL VALUES*

Viscosity@25℃, mPa.s[ASTM D-2983] .............................................................. 5000–12000



Non volatile component, wt% [DOWM-101188-TE].........................................................100



Density@25℃, g/ cm3 [ASTM D-1475] ................................................................. 1.10–1.20



Storage life@25℃(sealed container), month....................................................................12



Remark: To avoid water absorption, putting epoxy resin inside sealed container and keep at temperature 20-25℃ are suggested



JT 8897 B Pre catalytic liquid anhydride curing agent

TYPICAL VALUES*

Viscosity @ 25℃, mPa.s [ASTM D-2983] ................................................................1000-2500



Density @ 25℃, g/cm3 [ASTM D-1475] ................................................................ 1.15–1.25



Vapor pressure @ 25℃, mbar ......………………………………………………………………………………. 1 - 2



Storage life @ 25℃(sealed container), month....................................................................12

* typical value can not be regarded as product specs



Remark: This hardener is sensitive to water. If water content is high, which may change its reactivity, and finally change its performance. It must be stored in sealed container and kept in normal temperature( about 20–25℃).




Epoxy coating powder JT105 can be a useful material for electrical insulation of wire and busbars, as well as high performance motors. Here are some features and benefits of JT105 epoxy coating powder:

Electrical Insulation: Epoxy coating powder JT105 is an excellent electrical insulator, which makes it ideal for use in electrical insulation applications. It can help to prevent electrical current from flowing through the insulation, reducing the risk of electrical breakdown or short circuits.

Corrosion Protection: Epoxy coating powder JT105 is highly resistant to corrosion, which makes it a good choice for use in harsh environments, where exposure to moisture or other corrosive substances could cause damage or corrosion.

Chemical Resistance: Epoxy coating powder JT105 is highly resistant to chemicals, which makes it a good choice for use in applications where exposure to chemicals could cause damage or corrosion.

Mechanical Protection: Epoxy coating powder JT105 can also provide mechanical protection to the wire, busbars, or motor components. The coating can help to strengthen the components, making them more resistant to bending, cracking, or breaking.

Customizable: Epoxy coating powder JT105 can be formulated to meet specific performance requirements, such as low viscosity, high filler loading, or high thermal stability. This makes it a versatile material that can be customized to meet the needs of different applications.

Overall, epoxy coating powder JT105 can be an effective and reliable material for electrical insulation of wire and busbars, as well as high performance motors. Its combination of electrical insulation, corrosion protection, chemical resistance, mechanical protection, and customization options make it a popular choice for manufacturers of electrical equipment.
