No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy
  • No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy
  • No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy
  • No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy
  • No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy
  • No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy

No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy

Place of Origin China
Brand Name JT-RESIN
Certification ISO.CE.UL
Model Number JT8888
Product Details
Visual::
Transparent Sticky Liquid
MODEL:
JT8888
CAS No.::
25550-51-0
Place Of Origin::
HUBEI CHINA
EINECS No.::
247-094-1
Highlight:

No Postcure Injectable Epoxy Resin

,

Electrical Insulation Injectable Epoxy Resin

,

25550 51 0 Electrical Insulation Epoxy

Payment & Shipping Terms
Minimum Order Quantity
25KG
Price
$4/kg
Packaging Details
25kg/pail,5kg/pail
Delivery Time
5 days
Payment Terms
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability
200Ton/week
Product Description

Wholesale no postcure injecting epoxy resin apply to 10-35KV insulation LBS, BUSHINGS, SPOUTS, MONOBLOCK, SWITCH GEARS,



Insulating Material

Epoxy coating powder JT105 Product









100% thermosetting material Description



Class H epoxy coating powder



It is optimized for use in automated, high-speed electrostatic coating processes



Formulated with superior cut-through resistance and edge coverage, which is ideal



for high performance, densely wound electric motors







For high performance motors



For insulation of wire and busbars









Application











Excellent productivity Features



Shelf stable at room temperature (23℃/73°F)



Easy and affordable to store and use



Suitable for use in hot, humid climates conditions







No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy 0



Uncured Properties:



Hot Plate Gel time, seconds @ 160℃ 26

@210℃ 10

Stick point(℃) 70



Flow @ 150℃ (mm) 21



Particle size distribution ( %) -177 micron/ 80 mesh 100

-44 micron/ 325 mesh 27.5

Cure time ( seconds) @ 220℃ 45





Typical Cured General Properties:

Available colors Green and black



Density 1.6g/cm³



Edge Coverage (%) 41



Cut-through resistance (℃) 396



Volume resistivity (Ω-cm) 5.409 1016



Dielectric Strength V/ mil 1082

KV/ mm 42.6



Glass transition temperature, Tg (℃) 91

Cured 60 minutes @150℃



Coefficient of thermal Expansion, Alpha 1 39

CtE ( ppm/℃) Alpha 2 123





Storage & Handling:

  1. The shelf life is six months at room temperature (23℃/73°F) from production date.
  2. Shelf life may be extended under cold storage condition.
  3. Shelf life can be 18 months or more if stored at 10℃/ 50°F or below.
  4. The product should be stored in closed containers, which should be brought to the ambient.

Temperature of the manufacturing location before opening to prevent water condensation on the

  •
  1. Do not open the packaging while the product temperature is lower than the manufacturing room temperature, otherwise moisture will condense on the surface of product, which will damage the product and result in processing issues, such as incomplete curing.
  2. The time for temperature equilibration depends on the product, for example, 5kg will take about 4 hours to warm-up, however 50kg may require 12-24hours to equilibrate.No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy 1No Postcure Injectable Epoxy Resin , Cas No 25550 51 0 Electrical Insulation Epoxy 2
