| Place of Origin | China |
| Brand Name | JT-RESIN |
| Certification | SGS，CE,UL |
| Model Number | 888 |
| Input power of machine tool | 220v |
| 机床重量 Weight of machine tool | 60kg |
| 机床外形尺寸 Dimensions of machine tool | 600x600x1200mm |
| Model | ZDR-2 |
| Nominal diameter of enameled wire | Φ0.8~2.6mm |
| Max winding breadth | 260mm |
| Winding rotation speed range | 1440rpm |
| Voltage range of application | 10~35kv |
| Machine tool power | 1.5kw |
| Input power of machine tool | 220v |
| Weight of machine tool | 160kg |
| Dimensions of machine tool | 1100x700x1200mm |
| Product name | Secondary CNC winding machine for current transformer |
| Model | ZDL-2 |
| Nominal diameter of enameled wire | Φ0.8~2.6mm |
| Min & Max diameter of winded coils | Φ45~300mm |
| Winding rotation speed range | 1440rpm |
| Voltage range of application | 10~35kv |
| Machine tool power | 1.5kw |
| Input power of machine tool | 220v |
| Weight of machine tool | 160kg |
| Dimensions of machine tool | 1100x700x1200mm |
| Product name | CNC parallel winding machine for voltage transformer |
| Model | ZDT-1 |
| Nominal diameter of enameled wire | Φ0.10~3.0mm |
| Min & Max diameter of winded coils | Φ50~360mm |
| Distance between two centers | 500mm |
| Winding rotation speed range | 1440rpm |
| Voltage range of application | 10~35kv |
| Machine tool power | 1.5kw |
| Input power of machine tool | 220v |
| Weight of machine tool | 160kg |
| Dimensions of machine tool | 1200x700x1400mm |
| Product name | CNC rectangular winding machine for low voltage transformer |
| Model | ZDH-2 |
| Nominal diameter of enameled wire | Φ0.26~1.0mm |
| Max winding length | 180mm |
| Max winding width | 180mm |
| Winding rotation speed range | 1440rpm |
| Voltage range of application | 0.5~0.66kv |
| Machine tool power | 0.55kw |
| Input power of machine tool | 220v |
| Weight of machine tool | 60kg |
| Dimensions of machine tool | 600x600x1200mm |
| Model | ZDQ-2 |
| Nominal diameter of enameled wire | Φ0.26~1.0mm |
| Min inner & Max outer diameter of winded coils | Φ25~100mm |
| Winding rotation speed range | 1440rpm |
| Voltage range of application | 0.5~0.66kv |
| Machine tool power | 0.55kw |
| Input power of machine tool | 220v |
| Weight of machine tool | 60kg |
| Dimensions of machine tool | 600x600x1200mm |
