Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT
  • Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT

Insulation Resistance 10 16Ω APG Machine Epoxy Resin For Indoor Or Outdoor Transformer CT PT

Place of Origin CHINA
Brand Name JT-RESIN
Certification CE,UL
Model Number 8332A&B
Product Details
Operating Temperature:
-40°C To 150°C
Ratio:
100/100/300
LIQUID TYPE:
ADD FILLING
Insulation Resistance:
10^16Ω
Classification:
Double Components Adhesives
Thermal Conductivity:
0.2-0.3 W/mK
Hardness:
80-90 Shore D
Product Category:
Electrical Insulating Epoxy Resin
High Light:

10 16Ω APG machine Epoxy Resin

,

Insulation Resistance Epoxy Resin

Payment & Shipping Terms
Minimum Order Quantity
400kg
Price
$3/kg
Packaging Details
1200kgs/pail,250kg/pail,25kg/pail
Delivery Time
5 days
Payment Terms
L/C, T/T, Western Union, MoneyGram
Supply Ability
80ton/day
Product Description

Product Description:

This Double Components Adhesive is the perfect solution for Pin bushing for GIS Switch Gear, which requires a reliable and durable adhesive to keep the Pin bushing in place. This product can withstand harsh operating temperatures, ranging from -40°C to 150°C, making it ideal for use in extreme environments.

In addition to its excellent thermal properties, our Electrical Insulating Epoxy Resin also has a high glass transition temperature (TG) of 110-120, ensuring that the adhesive maintains its strength and integrity even under heavy loads.

Our Electrical Insulating Epoxy Resin is manufactured using the APG process with epoxy resin, which ensures that the adhesive is of the highest quality and meets strict industry standards. The APG process also ensures that the product has a long shelf life and is easy to use.

The curing process for this product is simple and straightforward. When cured at 140℃ for 10 hours, our Electrical Insulating Epoxy Resin provides a strong and durable bond that is resistant to heat, chemicals, and other environmental factors.

In summary, our Electrical Insulating Epoxy Resin is a high-performance adhesive that is perfect for Pin bushing for GIS Switch Gear applications. It is made from high-quality epoxy resin, has excellent thermal properties, and is easy to use. Its APG process with epoxy resin guarantees its quality and long shelf life. It is an ideal solution for applications that require a reliable and durable adhesive that can withstand harsh environments.


Features:

  • Product Name: Electrical Insulating Epoxy Resin
  • Industry: Electrical Insulator
  • Thermal Expansion Coefficient: 50-60 μm/m·K
  • Operating Temperature: -40°C To 150°C
  • Impact Strength: No Cracks
  • COMPOUND: 2
  • 10 TO 1100KV electric insulation
  • EPOXY RESIN AND CURING AGENT
  • CASTING PROCESS WITH EPOXY RESIN

Technical Parameters:

Sample Curing Conditions 10h @140℃
Classification Double Components Adhesives
Our Service One-Stop Service
Operating Temperature -40°C To 150°C
COLOR GREEN
TG 110-120
LIQUID TYPE ADD FILLING
Material Epoxy Resin and Curing Agent
Thermal Conductivity 0.2-0.3 W/mK
Application High Voltage (10 to 1100KV electric insulation)

Applications:

  • High voltage electrical insulation
  • Indoor or outdoor transformer CT PT
  • 10 to 1100KV electric insulation

Our electrical insulating epoxy resin is CE and UL certified and has a proven track record of performance and reliability. Made in China, our product is available for a minimum order quantity of 400kg at an affordable price of $3/kg.

With a supply ability of 80ton/day, we are able to meet the needs of even the largest projects. Our packaging options include 1200kgs/pail, 250kg/pail, and 25kg/pail, making it easy to customize your order to meet your specific needs. We accept a variety of payment terms, including L/C, T/T, Western Union, and MoneyGram, and our delivery time is just 5 days.

In addition to being a high-quality electrical insulating epoxy resin product, JT-RESIN's Model Number 8332A&B also offers impressive impact strength with no cracks and can operate in temperatures ranging from -40°C to 150°C. This makes it the perfect choice for a wide range of electrical insulation needs.

Don't settle for a subpar electrical insulating epoxy resin product. Choose JT-RESIN's Model Number 8332A&B for a reliable and high-quality solution that meets all of your needs.


Support and Services:

Our Electrical Insulating Epoxy Resin product is designed to provide excellent insulation for electronic components and devices. It offers high dielectric strength and thermal resistance, making it ideal for use in high-temperature environments. Our technical support team is available to assist with any questions or issues related to the product, including recommendations for proper handling, storage, and application. We also offer a range of services to support our customers, including custom formulations and technical training. Contact us for more information on our Electrical Insulating Epoxy Resin product and services.


Packing and Shipping:

Product Packaging:

  • 1 gallon (3.78 L) metal can
  • 5 gallon (18.93 L) metal pail
  • 55 gallon (208.20 L) metal drum

Shipping:

  • Ships via ground transportation
  • May require additional handling fees
  • Shipping available within the United States only

FAQ:

Q: What is the brand name of this Electrical Insulating Epoxy Resin?

A: The brand name of this product is JT-RESIN.

Q: What is the model number of this Electrical Insulating Epoxy Resin?

A: The model number of this product is 8332A&B.

Q: What certifications does this Electrical Insulating Epoxy Resin have?

A: This product is certified with CE and UL.

Q: What is the minimum order quantity for this Electrical Insulating Epoxy Resin?

A: The minimum order quantity for this product is 400kg.

Q: What is the price of this Electrical Insulating Epoxy Resin?

A: The price of this product is $3/kg.

Q: What is the supply ability of this Electrical Insulating Epoxy Resin?

A: The supply ability of this product is 80ton/day.

Q: What are the packaging details for this Electrical Insulating Epoxy Resin?

A: This product is packaged in 1200kgs/pail, 250kg/pail, and 25kg/pail.

Q: What are the payment terms for this Electrical Insulating Epoxy Resin?

A: The payment terms for this product are L/C, T/T, Western Union, and MoneyGram.

Q: What is the delivery time for this Electrical Insulating Epoxy Resin?

A: The delivery time for this product is 5 days.
