Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder
  • Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder
  • Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder
  • Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder
  • Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder
  • Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder

Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder

Place of Origin HUBEI, CHINA
Brand Name JT
Certification ISO
Model Number 634
Product Details
Packing:
25kg/bag, 48bags/pallet
SHAP:
SAND
COLOR:
WHITE
MODELNO.:
C07
Main Components:
Quartz Powder
Main Purpose:
FILLER
Current:
10A
Form:
Coil
Heat Resistance:
120℃
Insulation:
UL-94V-0
Length:
2000mm
Material:
Copper
Shape:
Rectangle
Surface:
Smooth
Thickness:
0.2mm
Tolerance:
±0.1mm
Voltage:
220V
Weight:
2.5kg
Width:
1000mm
High Light:

White Epoxy Silica Filler

,

Sand Epoxy Silica Filler

,

White High Purity Quartz Powder

Payment & Shipping Terms
Minimum Order Quantity
1200kg
Price
negotiable
Packaging Details
25 kg/bag, 48 bag/ pallet
Supply Ability
30 tons/week
Product Description

Elecrical Insulation Used of Silica Powder to Filling on Epxoy Resin and Hardener fo36KV PT



SILICA POWDER SAND FOR EPOXY RESIN

Added Scale 350~400 pbw



Product Description:

C634 SILICA SAND FOR EPOXY RESIN





Silica sand is a commonly used filler material in epoxy resin formulations. It is a type of sand that contains high levels of silica, which is a naturally occurring mineral that is commonly used in various industrial applications due to its unique properties.

Here are some of the benefits of using silica sand as a filler in epoxy resin:

Improved mechanical properties: Silica sand can help to improve the mechanical properties of epoxy resin, such as its hardness, strength, and abrasion resistance. This is because the sand particles add reinforcement to the epoxy matrix, making it stronger and more durable.

Cost-effective: Silica sand is a relatively inexpensive material, making it a cost-effective filler option for epoxy resin formulations.

Good flow properties: Silica sand has good flow properties, which means that it can be easily mixed into the epoxy resin and applied evenly to the surface being coated.

Improved adhesion: Silica sand can also help to improve the adhesion of epoxy resin to the surface being coated, which can help to prevent delamination and other adhesion-related problems.

Improved thermal properties: Silica sand can also help to improve the thermal properties of epoxy resin, such as its resistance to heat and thermal shock.

Overall, silica sand is a versatile and useful filler material for epoxy resin formulations. Its unique properties can help to improve the mechanical, thermal, and adhesive properties of the resin, while also making it more cost-effective and easier to work with.

Granulometric Data & Physical Characteristics

Mean values. These do not represent a specification



Residual(µm) 150            -----                          %

106                               0.02                          %

75                                 0.05                          %

45                                  1.70                         %

38                                  7.95                         %

Laser Particle size

(µm) 2                            10.48                     %



D10                                 1.87                      µm

D50                                 18.07                     µm

D90                                  50.34                    µm

Surface Area, Blaine        1.10                    m2/g

Oil Absorption                  18.50                    g/100g

PH                                     6.63

Whiteness 90.13

  Bulk density, loose              0.70                 g/cm3



Moisture                                 0.02                    %



Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 0Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 1







Hubei Plant and Guangdong plant:

Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 2



Test equipment:

Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 3

MY CLIENTS:



Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 4

Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 5



ISO Certificate:

Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 6Sand White Epoxy Silica Filler , Elecrical Insulation High Purity Quartz Powder 7



FAQ:



1. We’re using Huntsman epoxy resin, can I use JiangTe resin?

Yes,ours are equivalent to Huntsman. Please tell the number of Huntsman you’re using, we’ll offer the one matching.



2. What’s the pot life?

Pre-filled resin is one year; Pure resin is 2-3 years.



3. We’re just starting producing. Can you help us on the process?

No problem, we’ll offer guidance and support. We have thousands of customer manufacturers in China and overseas.

So we have good experiences.
